Brand

Schneider

Model Name

Zelio

Product Code | Control Circuit Voltage

RXM4AB2JD | 12 V DC

RXM4AB2B7 | 24 V AC

RXM4AB2BD | 24 V DC

RXM4AB2E7 | 48 V AC

RXM4AB2ED | 48 V DC

RXM4AB2FD | 110 V DC

RXM4AB2F7 | 120 V AC

RXM4AB2GD | 125 V DC

RXM4AB2P7 | 230 V AC

Product Type

Plug In Miniature Relays

Series Name

Miniature

Device Short Name

RXM

Description

4 Change Over - 6 AMPS Contact Rating

Current Rating

6 A

Contacts Type And Composition

4 C/O

Utilisation Coefficient

20 %

Status LED

With

Control Type

Lockable Test Button

Shape Of Pin

Flat

Mechanical Durability

10000000 cycles

Maximum Switching Voltage

250 V Conforming To IEC

Operating Position

Any Position

Product Weight

0.037 Kg

Warranty

As Per Manufacturer Terms And Condition
